1064nm 7 Jointed Articulated Arm Q Switched ND Yag Red Diode Laser
Machine For Tattoo
Introduction:
Specially designed 1064nm, 532nm, 755nm three wavelength laser
system, use of lightweight and ergonomic treatment handle allows
the spot size on the skin to be easily adjusted for safe and
effective removal of tattoos and benign pigment lesions. Optional
array focus lens, greatly improve the pox pit, pockmark, dull skin,
rough skin conditions.
what is picosecond laser?
A picosecond laser is a laser device that uses very short pulse
durations to target endogenous pigmentation and exogenous ink
particles (tattoos). The medium varies accordingly to the
wavelength being used, whether the neodymium-doped yttrium
aluminium garnet (Nd:YAG) crystal (532 nm or 1064 nm), or the
Alexandrite crystal (755 nm).
Parameter
Model No. | PL-10 |
Flash Lamp-excited | Q-Switched Nd:Yag Laser |
Wavelength | 1064nm&532nm&755nm |
Pulse width | <5ns |
Delivery system | 7 jointed articulated arm |
Display | 10.4 inch true color touch screen |
Indicator | Red diode laser aiming beam |
Repeat rate | 1-10Hz |
Spot Size | 1-10mm(1mm step) |
Maximum Energy | 2000mj |
Power | 2000W |
Cooling System | Water+wind cooling |
Gross weight | 60kg without arm |
Packing size | 61cm*104cm*114cm |
Application
Ota nevus, brown green moles, age spots, coffee spots, freckles,
red blood and other skin spots
Black, blue, brown, red or even green tattoo
Eye filaments, loose skin and other aging skin problems
Pox pit, pockmark, dull, rough skin conditions
Advantages:
1. 3 laser wavelengt: 1064nm, 532nm, 755nm
2. 7 jointed guiding arm: max energy output , uniform spot density
3. Super cooling system: make sure energy stable, powerful
4. 1-10mm spot size adjustable handle with aiming beam: easy, quick
adjust, professional
5. 2000W Dual-lamp pump laser: highest energy, best treatment
result.
6. <5ns Pulse width: ensure best treatment experience, shorten
treatment times.
